DSPA 12 Series Aerosol Generator

DSPA 12 Series Aerosol Generator

Properties

  • Exceptional effective non-toxic fire extinguishing agent
  • Uniquely easy to install and Maintain
  • Tested as per EN 15276-1, NEN-ISO 15779, UL 2775 and BRL K23001
  • Approved by EPA for SNAP listing
  • Ecologically safe and environmentally friendly (O.D.P.=0, G.W.P.=0)
  • Very cost efficient

Description

Standalone aerosol fire extinguishing units with a thermal starter from the DSPA 12 series (DSPA 12-1, 12-2, 12-3, 12-4, 12-5) are intended to control and extinguish fires of flammable and combustible liquids, solid fuels and electrical equipment, including energized ones. The DSPA 12-1, 12-2, 12-3, 12-4 are also available with an electrical starter that can be connected to a control module.

Application

The generators are used for fire protection of small volumes (electric cabinets, engine compartments, etc.) and vehicles.

No items found.
No items found.
Model
Dimensions
Part number
Total weight
Compound weight
Volume coverage

Discharge time
Activation, current
Operation conditions
Colour
12-1
Ø100 x 20,3 mm
Ø3.94" x 0.8"
100020 (E) 100025 (T)
0,1 kg
0.22 lbs
0,015 kg
0,15 m³
5.3 ft³
9-11 sec
12-2
Ø100 x 34 mm
Ø3.94" x 1.34"
100021 (E) 100026 (T)
0,15 kg
0.33 lbs
0,03 kg
0,29 m³
10.24 ft³
13-15 sec
12-3
Ø130 x 21 mm
Ø5.12" x 0.83"
100022 (E) 100027 (T)
0,5 kg
1.1 lbs
0,055 kg
0,54 m³
19 ft³
9-11 sec
12-4
Ø 130 x 29 mm
Ø 5.12" x 1.14"
100023 (E) 100028 (T)
0,65 kg
1.43 lbs
0,11 kg
1,07 m³
37.79 ft³
11-14 sec
12-5
Ø 80 x 16 mm
Ø 3.15" x 0.63"
100024 (T)
0,07 kg
0.15 lbs
0,005 kg
0,05 m³
1.77 ft³
5-7 sec
Built-in starter, 1.3A (e) or built-in thermocord (t)
-40°C to 75°C/ -40°F to 167°F Up to 95% RH
Standard RAL 3000, other colours upon request
